Application area:
It is suitable for blood component separation, nucleic acid extraction, cell component separation, etc., widely used in clinical testing, life science, bioengineering, biochemistry, medical research, agriculture and animal husbandry, biopharmaceutical and food and other fields.
Product features:
1.steel body, large torque brushless AC frequency conversion motor drive: no toner pollution, low noise, small vibration, high speed control precision.
2.programmable color touch screen and 8-button dual operating system for users to choose freely. The interface can display: rotation speed, centrifugal force, running time, rotor number and details, lifting rate, etc.; with touch screen lock function to prevent misoperation.
3. Built-in 10 kinds of up / down gear, which can be customized according to the experimental requirements, to ensure that the centrifugal effect is good.
4. The use of imported high-efficiency and environment-friendly refrigeration system, intelligent pre-cooling, fast refrigeration speed, low noise, high temperature control precision, optional heating module.
5,.The use of multi-stage damping damping design, special noise reduction technology: small noise, small vibration, good centrifugal effect.
6.With the door cover, misoperation and other diagnostic functions, the machine can directly display the fault information, easy to judge and repair, to ensure the safety of man-machine.
Company Name :
Hunan Anjunyan Instruments Co., Ltd.Brand :
ANJUNYANHunan Anjunyan Instrument Co., Ltd. is a collection of design, research and development production, sales and sales, after the service as one of the professional high-tech manufacturing enterprises.
Anjunyan main products for centrifuge and other special instruments and equipment, using domestic, high technology, continuous introduction of high-end people, only, continuous development and innovation, has passed the international CE product certification and ISO9001:2015 quality management system certification, for domestic and foreign university institute, biological products, food hygiene, pharmaceutical companies, industry, blood stations, medical institutions and other fields provide high quality products.
Company concept: safety with you, fine drill fine research.
Company vision: to create business value to meet customers' expectations and
become an excellent enterprise in the centrifuge industry.
Company values: customer-centered, hard work, sustainable learning, and continuous innovation.
①Vertical ultra-high-speed refrigerated centrifuge
It is widely used in pharmaceutical factories, biochemistry, biological products and other production and scientific research units Perform experiments such as protein precipitation and cell isolation and collection in large quantities.
②High-speed refrigerated centrifuge
It is applicable to the separation of molecular biology, blood components, cellular components, and protein purification, and is widely utilized in fields such as clinical medicine, life sciences, bioengineering, biochemistry, medical research, agriculture, and biopharmaceuticals.
③Low-speed refrigerated centrifuge
It is applicable for the separation of blood components, nucleic acid extraction, and cellular component separation, and is widely used in clinical testing, life sciences, bioengineering, biochemistry, medical research, agriculture, biopharmaceuticals, and food industries.
④Low-speed centrifuge
It is applicable for the separation of blood components, nucleic acid extraction, and cellular component separation, and is widely used in clinical testing, life sciences, bioengineering, biochemistry, medical research, agriculture, biopharmaceuticals, and food industries.
Technical parameter:
1. Maximum rotation speed: 6,000r/min
2. Maximum centrifugal force: 6,080×g
3. Maximum capacity: 4×1000 ml
4. Speed accuracy: ±10r/min
5. Timing range: 0-99h59min59s
6. Complete machine noise:65dB (A)
7. Power supply/total power: Ac220V 50Hz 10A/1000W
8. Net weight: 136KG
9. Overall dimension:680mm×630mm×830mm(L×W×H)
Adapt to the rotor
|
Rotor number |
name |
Rotor capacity |
maximum speed |
Maximum relative centrifugal force |
Centrifuge tube size (mm) |
|
01 |
Angle rotor |
12×15ml / 10ml / 5ml (stainless steel sleeve) |
6000r/min |
6080×g |
φ16×100-120 |
|
02 |
Horizontal rotor body |
800ml (frame) |
4000r/min |
2920×g |
Configuration rack (required) |
|
0201 |
pylons |
8×100ml |
4000r/min |
2920×g |
φ38×113-118 |
|
0202 |
pylons |
8×50ml |
4000r/min |
2920×g |
φ29×106-107 |
|
0203 |
pylons |
32×15ml |
4000r/min |
2920×g |
φ16×100-120 |
|
03 |
Horizontal rotor |
4×500ml (flat-bottom round cup) |
4000r/min |
3480×g |
φ79×137 |
|
0301 |
adapter |
68×5ml / 2ml (blood collection vessel) |
4000r/min |
3300×g |
φ13×75-100 |
|
0302 |
adapter |
68×1.5ml/2.2ml |
4000r/min |
3300×g |
φ10×42 |
|
0303 |
adapter |
32×15 / 10ml (round bottom / pointed bottom) |
4000r/min |
3300×g |
φ16×100-120 |
|
0304 |
adapter |
12×50ml (round bottom) |
4000r/min |
3300×g |
φ29×106-107 |
|
0305 |
adapter |
4×100ml (round bottom) |
4000r/min |
3300×g |
φ38×113-118 |
|
0306 |
adapter |
4×250ml (flat-bottom round cup) |
4000r/min |
3049×g |
φ61.5×126 |
|
04 |
Horizontal rotor |
4×500ml (square cup) |
4000r/min |
2910×g |
Configure the adapter (required) |
|
0401 |
adapter |
80×5ml / 2ml (auto-removal) |
4000r/min |
2910×g |
φ13×75-100 |
|
0402 |
adapter |
80×1.5ml/2.2ml |
4000r/min |
2910×g |
φ10×42 |
|
0403 |
adapter |
48×15ml/10ml |
4000r/min |
2910×g |
φ16×100-120 |
|
0404 |
adapter |
20×50ml |
4000r/min |
2910×g |
φ29×106-107 |
|
0405 |
adapter |
8×100ml |
4000r/min |
2910×g |
φ38×113-118 |
|
05 |
Horizontal rotor |
4×600ml (square cup) |
4000r/min |
3480×g |
Configure the adapter (required) |
|
0501 |
adapter |
100×5ml / 2ml (extraction vessel) |
4000r/min |
3480×g |
φ13×75-100 |
|
0502 |
adapter |
100×1.5ml/2.2ml |
4000r/min |
3480×g |
φ10×42 |
|
0503 |
adapter |
48×15ml/10ml |
4000r/min |
3480×g |
φ16×100-120 |
|
0504 |
adapter |
20×50ml |
4000r/min |
3480×g |
φ29×106-107 |
|
0505 |
adapter |
16×100ml |
4000r/min |
3480×g |
φ38×113-118 |
|
06 |
Horizontal rotor |
4×750ml (flat-bottom round cup) |
4000r/min |
3578×g |
φ98×140 |
|
0601 |
adapter |
104×5ml / 2ml (blood collection) |
4000r/min |
3578×g |
φ13×75-100 |
|
0602 |
adapter |
104×1.5ml/2.2ml |
4000r/min |
3578×g |
φ10×42 |
|
0603 |
adapter |
52×15/10ml |
4000r/min |
3578×g |
φ16×100-120 |
|
0604 |
adapter |
20×50ml |
4000r/min |
3578×g |
φ29×106-107 |
|
07 |
Horizontal rotor |
6×500ml (round cup, with air hood) |
4000r/min |
3600×g |
φ79×137 |
|
0701 |
adapter |
102×5ml / 2ml (blood collection) |
4000r/min |
3600×g |
φ13×75-100 |
|
0702 |
adapter |
102×1.5ml/2.2ml |
4000r/min |
3600×g |
φ10×42 |
|
0703 |
adapter |
48×15/10ml |
4000r/min |
3600×g |
φ16×100-120 |
|
0704 |
adapter |
18×50ml |
4000r/min |
3600×g |
φ29×106-107 |
|
0705 |
adapter |
6×100ml |
4000r/min |
3600×g |
φ38×113-118 |
|
0706 |
adapter |
6×250ml |
4000r/min |
3600×g |
φ61.5×126 |
|
08 |
Horizontal rotor |
4×800ml (square cup, with air hood) |
4000r/min |
3440×g |
Configure the adapter (required) |
|
0801 |
adapter |
120×5ml / 2ml (automatic extraction) |
4000r/min |
3440×g |
φ13×75-100 |
|
0802 |
adapter |
120×1.5ml/2.2ml |
4000r/min |
3440×g |
φ10×42 |
|
0803 |
adapter |
64×15/10ml |
4000r/min |
3440×g |
φ16×100-120 |
|
0804 |
adapter |
20×50ml |
4000r/min |
3440×g |
φ29×106-107 |
|
0805 |
adapter |
16×100ml |
4000r/min |
3440×g |
φ38×113-118 |
|
09 |
Horizontal rotor |
4×1000ml (oval cup with hood) |
4000r/min |
3600×g |
Configure the adapter (required) |
|
0901 |
adapter |
168×5ml / 2ml (extraction vessel) |
4000r/min |
3600×g |
φ13×75-100 |
|
0902 |
adapter |
168×1.5ml/2.2ml |
4000r/min |
3600×g |
φ10×42 |
|
0903 |
adapter |
92×15/10ml |
4000r/min |
3600×g |
φ16×100-120 |
|
0904 |
adapter |
28×50ml |
4000r/min |
3600×g |
φ29×106-107 |
|
0905 |
adapter |
20×100ml |
4000r/min |
3600×g |
φ38×113-118 |
|
10 |
Horizontal rotor |
4×2×96-well (microplate) |
4200r/min |
3155×g |
125× 85× 16.2 |
