DRP hydraulic coupling Roots pump
Company Name :
Shanghai Aifa Technology Co., Ltd.Brand :
AIFAFounded in 2009, Shanghai Aifa Technology Co., Ltd. is an enterprise integrating R&D, production, sales and after-sales service of dry vacuum pumps and vacuum solvent recovery systems, headquartered in Pudong New Area, Shanghai, the economic center.
The company has carried out in-depth cooperation with major domestic professional colleges and universities, professional chemical and pharmaceutical enterprises, and its products are jointly developed and designed with experts in chemical, pharmaceutical, environmental protection and other industries, and the equipment process, processing and manufacturing, performance and after-sales service are in the forefront of the domestic level.
1.DCP claw-type vacuum pump
Features:
① Verified through industry practice and proven over time.
② Specifically designed for chemical applications.
③ Carefully designed and tested to ensure safety and reliability.
④ Stable operation, even during process anomalies.
⑤ Low operating costs.
⑥ Easy to maintain, low power consumption, and does not require the injection of cooling gas.
2.VDP Screw Vacuum Pump
Features:
① Wide pumping speed range allows for direct atmospheric discharge, achieving the effect of multi-stage series operation with just a single pump.
② The single-stage design can achieve a vacuum level of 5 PA.
③ Nitrogen gas purging can be employed; cleaning and maintenance operations are simple, and repairs are convenient.
④ The screw is made of integral ductile iron, providing high strength and stable performance; the screws do not contact each other, eliminating friction, requiring no lubrication grease, preventing oil backflow, and eliminating waste gas and liquid discharge, making it clean, environmentally friendly, and energy-efficient.
⑤ The internal pump chamber and components can be surface-treated for corrosion resistance as needed, making it suitable for the special requirements of the chemical and pharmaceutical industries. 6. The screw undergoes precise dynamic balance correction, ensuring smooth operation, low noise, minimal vibration, and a long service life.
3.DRP Hydraulic Coupling Roots Pump
Features:
① The hydraulic transmission structure allows the Aifaluo Roots pump to start directly under atmospheric pressure or high differential pressure.
② The Roots pump can start and stop simultaneously with the primary pump. The Roots pump can automatically adjust its speed, preventing overload or overheating. Starting the Roots pump in advance under high differential pressure can reduce pumping time and improve the system's pumping efficiency.
③ In the event of foreign objects entering the pump chamber or sudden pressure changes, it automatically reduces speed for protection, resulting in an extremely low failure rate.
④ Simple configuration, no need for bypass pipelines, valves, or frequency converters, thus saving costs and facilitating convenient operation.
⑤ Operates smoothly and quietly, with minimal vibration, and the pump maintenance is straightforward.
The DRP series hydraulic couplings for Roots pumps are based on the traditional Roots principle. The mechanical booster pump is a widely popular type suitable for applications requiring a high pumping speed within a pressure range of 1 Pa to 1000 Pa. It typically requires a main pump to operate, with the Roots pump used to enhance the system's pumping speed and vacuum level, while avoiding exposure to corrosive process media at the same concentration as the main pump, thereby ensuring high reliability.
When the DRP Roots pump is used in conjunction with a primary oil-free dry pump, it can form an oil-free vacuum system. The role of the Roots pump is to increase the system's pumping speed and improve the vacuum level. The Aifa Roots pump employs advanced hydraulic drive technology, allowing for automatic speed adjustment, enabling it to start under atmospheric pressure or simultaneously with the main pump, significantly simplifying system configuration and operation while greatly enhancing system reliability.
The hydraulic drive structure allows the Aifa Roots pump to start directly under atmospheric pressure or high differential pressure.
The Roots pump can be started and stopped simultaneously with the main pump.
The Roots pump can automatically adjust its speed to prevent overload or overheating. The Roots pump can start in advance under high differential pressure, thereby reducing pumping time and improving system pumping efficiency.
When foreign objects enter the pump chamber or when pressure changes suddenly, automatic deceleration protection is activated, resulting in an extremely low failure rate.
The configuration is simple, requiring no bypass piping, valves, or frequency converters, thus saving costs and facilitating operation.
It operates smoothly and quietly, with minimal vibration, and the maintenance of the pump is very straightforward.
Application fields include pharmaceuticals, chemical engineering, electronics and photovoltaics, metallurgy, aerospace, and nuclear industry.
Technical Specifications
|
Model
|
Unit
|
DRP250
|
DRP500
|
DRP1200
|
DRP2600
|
DRP4200
|
|
Pumping Speed
|
m³/h
|
250
|
500
|
1200
|
2600
|
4200
|
|
Standard Motor Power
|
kW
|
2.2
|
3
|
4
|
7.5, 11
|
11
|
|
Max Speed
|
rpm
|
0-3600
|
||||
|
Pressure Differential
|
Pa
|
0-18,000
|
0-11,000
|
0-8,000
|
0-7,500
|
0-6,000
|
|
Working Temp
|
°C
|
5-40
|
||||
|
Inlet Connection
|
DN
|
80
|
100
|
125
|
150
|
250
|
|
Outlet Connection
|
DN
|
50
|
80
|
100
|
100
|
150
|
|
Weight with Standard Motor
|
kg
|
150
|
160
|
280
|
380
|
450
|
